OEM Battery To Starter Junction Cable Wire
Common knowledge about battery To Starter Cable wiring:
There are two sizes of battery pile heads according to different battery series: one is a cone with a positive diameter of 17.5mm and a cone with a negative diameter of 16mm; the other is a cone with a positive diameter of 12.5mm and a negative diameter of 12.5mm. 11mm cone (for small displacement models). The inside of the battery connector (battery clip) is also a cone, the minimum inner diameter is the same as the pile head, and the maximum inner diameter is calculated according to the taper of 1:9. After the battery pile head is installed on the battery, it should be smeared with Vaseline or butter to prevent oxidation and ensure reliable conduction.
Selection of Battery To Starter Cable:
Wire: high temperature resistant wire or irradiated wire [QVR-105℃, AEX(F), STX, SGX];
Bellows: Nylon (PA);
Dust jacket: fluorine rubber, EPDM or neoprene;
Tape: cloth base or high temperature resistant tape (gray);
Terminals: matt tin plated; battery clips - copper tin plated or zinc, lead-tin alloy;
Heat shrinkable tube: cross-linked polyolefin (PE), continuous use temperature -55~125℃.
Product parameters:
|
products name
|
OEM Battery To Starter Junction Cable Wire
|
|
Material
|
Wire: high temperature resistant wire or irradiated wire [QVR-105℃, AEX(F), STX, SGX];
Bellows: Nylon (PA); Dust jacket: fluorine rubber, EPDM or neoprene; Tape: cloth base or high temperature resistant tape (gray); Terminals: matt tin plated; battery clips - copper tin plated or zinc, lead-tin alloy; Heat shrinkable tube: cross-linked polyolefin (PE), continuous use temperature -55~125℃. |
|
Connector
|
All kinds of connectors are available
|
|
Color
|
All colors are available
|
|
MOQ
|
Welcome Small quantity, even 100pcs
|
|
Standards
|
Under IPC/WHMA-620 Standards
|
|
Quality
|
100% tested before delivery, Never use Fake materials
|
